Eartec UltraLITE PRO16 ETP2S – 2-person intercom
Wireless full-duplex 2.4 GHz system, range up to 914 m
article number: 12685 | manufacturer number: ETP2S
The Eartec UltraLITE PRO16 ETP2S is the compact professional communication solution for two people. The wireless intercom system is ideal for camera and direction, presenter and technology, interview situations, streaming or mobile productions with direct coordination.
Both participants can speak and listen at the same time - without pressing a button, without cables and without a base station. This keeps your hands free and work processes become significantly more efficient.
The PRO16 series offers professional radio technology with a long range of over 800 meters, two channels and excellent speech intelligibility even in noisy environments.
- Camera and direction
- Moderator and technology
- Drone pilot and spotter
- Photographer and assistant
- Industrial or Construction site coordination
- Full duplex communication
- No talk button necessary
- License-free 2.4 GHz system
- Up to a range of over 800 meters
- Up to 10 hours of battery life
- Can be extended later up to 16 Participants
- 1 x Master Single Headset
- 1 x Remote Single Headset
- 2 Batteries
- 2-fold charger
- Soft case
Real product can look different to picture
techn. Specs▲
Techn. Data
| Frequency | 2407 MHz – 2475 MHz |
|---|---|
| Reception frequency range | 2407 MHz – 2475 MHz |
| Maximum Transmission power | 80 mW |
| Type of use | Automatic frequency hopping |
| Channel tuning step | ≥2 M |
| Weight | 215 g |
| Channel bandwidth | 2 M |
| Modulation type | FLRC |
| Transmission speed | 1.3 MBPS |
| Duplexing | Time Division Duplexing (TDD) |
| Speech coding | ADPCM / 16bit/s |
| RF access | Time division multiplexing (TDMA) |
| Range | max. 914 meters (line of sight, depending on terrain) |
| Headset power supply | Rechargeable LiPo battery 3.7 V |
| Charger power supply | 5 V |
| Operating time | 10 hours |
| Normal use temperature | 0 C to 45 C |
| Storage temperature | 0 to 30 C |
Questions & Answers▲
How many people can communicate with the Eartec UltraLITE PRO16 ETP2S at the same time?
The set is designed for 2 people and contains a master headset and a remote headset. However, the system can be expanded to up to 16 users if appropriate additional devices are added.
Is a base station required for operation?
No, the system works without a base station. Communication takes place directly between the headsets, which significantly simplifies the setup and makes the system particularly suitable for mobile use.
What range does the system have in practical use?
The specified range is 300 to 400 meters depending on the environment. According to the manufacturer, up to 914 meters can be achieved under optimal outdoor conditions. The range may be lower in buildings or when there are obstacles.
What does full duplex mean in this intercom system?
Full duplex means that everyone involved can speak and hear at the same time without having to press a talk button. There is no cutting of conversations, which enables natural, delay-free communication.
At what frequency does the system work and is it susceptible to interference?
The system works in the 2.4 GHz frequency range between 2407 MHz and 2475 MHz. To minimize interference, it uses Automatic Frequency Hopping, which automatically switches to interference-free channels.
How long does the battery last when fully charged?
The battery life is up to 10 hours, which is suitable for all-day productions and longer events are sufficient. The scope of delivery includes batteries and a charger.
Which headset design is included in the set?
The set includes two one-sided one-ear headsets, a single master headset and a single remote headset. This design makes it possible to keep one ear free so that ambient noise can still be heard.
For which areas of application is the system particularly suitable?
The system is particularly suitable for video recordings, live streaming, interviews, directing work and small production teams. Typical combinations of use include cameraman and director or presenter and studio technology.
Is the system comfortable for longer periods of wear?
The headsets are lightweight and designed for longer, comfortable wear. The one-sided design further increases wearing comfort, as there is no complete hearing protection.
What is included in the set?
The scope of delivery includes a single master headset, a single remote headset, batteries, a charger and a soft case transport bag included.
Can the 2-person set be subsequently expanded to include more participants?
Yes, the system is expandable. The PRO16 series supports up to 16 users simultaneously. By purchasing additional remote headsets, the existing set can be expanded accordingly.
How many channels are available?
The system has 2 channels. In combination with the automatic frequency hopping technology, a stable and largely interference-free transmission is guaranteed.
Is the system well suited for transport?
Yes, the delivery includes a soft case transport bag in which the entire set is safe can be stored and transported. The slim design of the headsets supports compact, mobile use.
documents, files, links▲
eartec-pro1-user-manual-deutsch.pdf
add-a-headset-pro16-programming.mp4product safety (GPSR)▲
