Varizoom Vztft 5.6 Dual-Rackmount 19 Inch Rack
Professional accessory for demanding productions
Special price: € 249.00
incl. VAT
( instead of 1092.37 )
209.24 € w/o vat
in stock
Shipping costNo returned or B-stock items sold as new
One contact who knows the equipment
Not left alone if a defect occurs
Full input-tax deduction for business customers
article number: 7232 | manufacturer number: VZTFT5.6DUAL
The Lilliput VZTFT5.6DUAL is a 19 inch TFT monitor bridge with two integrated 5.6 inch LCD monitors in 4:3 format. The monitors are suitable for simple video surveillance, control applications, industrial use, CCTV systems and universal composite video signals.
Each monitor has its own video input via RCA / Composite Video. The display operates in NTSC or PAL format with automatic switching. This allows the monitor bridge to be used flexibly with compatible video sources.
The 19 inch form factor enables installation in racks, equipment cabinets or control stations. With a width of 483 mm and a height of 185 mm, the unit is suitable for compact monitoring and control applications where two video signals need to be monitored simultaneously.
- CCTV and surveillance systems
- Industrial and control applications
- Video monitoring with composite signals
- Rack installation in 19 inch environments
- Technical workstations, control rooms and basic video monitoring
Remaining stock / clearance sale. The monitor bridge is intended for simple composite video applications.
2 x power supply, 2 x composite cable and data sheet included in scope of delivery
Real product can look different to picture
techn. Specs▲
| General | |
| Product Type | 19 inch TFT monitor bridge with 2 LCD monitors |
|---|---|
| Number of Monitors | 2 x 5.6 inch LCD monitor |
| Aspect Ratio | 4:3 |
| Rack Width | 19 inch / 483 mm |
| Monitor Bridge Height | 185 mm |
| Display per Monitor | |
| Display System | Active-Matrix TFT-LCD |
| Active Display Area | approx. 113 x 85 mm |
| Resolution | 960 x 234 pixels |
| Brightness | 300 cd/m² |
| Viewing Angle | 30° / 10° / 45° top / bottom / left-right |
| Video System | NTSC / PAL, automatic switching |
| Video and Connections | |
| Video Input | RCA Composite Video |
| Video Signal | 1 Vp-p, positive, 75 Ohm |
| Audio Monitoring | Possible via ear phone connector |
| Power Supply | |
| Input Voltage | 12 V DC ±15 % |
| Power Consumption | max. 8 W |
| Controls and Settings | |
| Image Settings | Color and brightness |
| Controls | AV Input, Ear Phone, Color, Brightness, Power, Volume |
| Dimensions and Weight per Monitor | |
| Monitor Dimensions | approx. 156 x 126 x 35 mm |
| Weight per Monitor | approx. 408 g |
| Environment | |
| Operating Temperature | 0 °C to +60 °C |
| Operating Humidity | max. 85 % |
Questions & Answers▲
What type of video input does each monitor support?
Each of the two 5.6-inch LCD monitors has its own dedicated RCA composite video input. No other input types such as HDMI, VGA, or SDI are supported. The unit is designed exclusively for composite video signals.
Does the monitor bridge support both NTSC and PAL signals?
Yes. Each monitor automatically detects and switches between NTSC and PAL formats. No manual configuration is required when connecting compatible composite video sources.
What is the native resolution of each LCD panel?
Each 5.6-inch LCD panel has a native resolution of 960×234 pixels. This resolution is typical for small composite video monitors used in CCTV and basic control applications.
Can both monitors display different video sources simultaneously?
Yes. Since each monitor has its own independent RCA composite input, two separate video sources can be connected and displayed at the same time without any switching required.
What are the physical dimensions of the unit?
The unit measures 483 mm in width, which corresponds to the standard 19-inch rack format, and 185 mm in height. It is designed for installation in standard 19-inch equipment racks and control cabinets.
Is the VZTFT5.6DUAL suitable for permanent rack installation?
Yes. The 19-inch form factor makes it compatible with standard rack systems used in control rooms, industrial environments, and technical workstations. The unit can be mounted directly into any 19-inch rack or equipment cabinet.
What display technology is used in the monitors?
Both panels use active-matrix TFT-LCD technology. The aspect ratio of each screen is 4:3, which matches the standard format of composite video signals from CCTV cameras and analog video sources.
Is this product suitable for high-resolution video monitoring?
No. The unit is designed for simple composite video applications with a resolution of 960×234 pixels per panel. It is not intended for high-resolution or digital video monitoring and is best suited for basic CCTV and control tasks.
What is included in the scope of delivery?
The package includes two power supplies, two composite cables, and a data sheet. No additional adapters or mounting hardware are specifically listed as included.
Is this product still in regular production?
No. The VZTFT5.6DUAL is available as remaining stock and is being sold as a clearance item. Availability may be limited and purchasing is recommended while stock lasts.
Can this monitor bridge be used with modern IP cameras?
No. The unit accepts only analog composite video signals via RCA connectors. IP cameras output digital network streams and are not compatible without an external analog converter, which is not part of the scope of delivery.
Is the unit suitable for industrial environments?
Yes. The monitor bridge is described as suitable for industrial and control applications. Its rack-mount design and composite video compatibility make it practical for use in factory environments, technical workstations, and similar settings where analog video monitoring is required.
