VariZoom Quickjib Camera Crane
Jib includes DCR100 Dolly and TCR100 Tripod
VZQUICKJIBKIT CAMERA JIB CAMERA CRANE The QuickJib from VariZoom represents the perfect balance of quality and economy in a thoughtful design. This is the answer for those who love all the options of the SnapCrane but are not willing to spend so much money. The Quick Jib offers you many of the features of the capture crane at an affordable price. With the Quick Jib, you get an economical but safe, non-losable clamp system for extending the boom, along with stainless aircraft pins attached to a lanyard for quick assembly. The QuickJib is a professional, tool-free jib arm that can be quickly and safely assembled. Like all our products, the QuickJib has been developed for years of trouble-free and reliable operation in the field. With great attention to detail, we have created a tool that will be treated with care for generations.
Starting with the simplest package (boom only) to our complete system (recommended), which includes dolly and tripod legs, you will see that safety is the highest priority.
Jib Arm
The QuickJib uses selective industrial powder coating and anodizing for lasting cosmetics, with stainless steel fasteners. The sleek QuickJib outperforms the competition with less air resistance using a four-arm support system (never use in high wind conditions) in windy conditions as cantilever arms. The QuickJib is mounted on any 100mm tripod, although we only recommend non-telescoping legs for safety reasons.
Braking System
The VariZoom braking system uses a heavy-duty plate that is firmly connected to the swivel range. The brake compression system is integrated into the left stator of the pan/tilt base and designed to add significant variable resistance, but makes enough mistakes to slide under extreme force that could otherwise overturn a parking brake boom system.
Locking Pins
High-quality, high-strength stainless aircraft bolts are used at the pivot points, secured by a connector to prevent them from being lost.
Tilting Mechanisms
Camera platform and tilt base connect the boom arm with stainless aircraft pins, which are introduced through sealed radial ball bearings at the tilt base and high-performance plain bearings at the camera platform, resulting in quiet, smooth motion. The camera platform also features a built-in spirit level for quick reference and adjustment.
Telescoping Counterweight Section
Telescopic weight arm with up to 3 feet for enormous flexibility. Extend the arm to reduce the required weight, shorten it to work in tighter spaces, or simply adjust it to fine-tune the counterweight.
DCR100 Dolly
Our heavy-duty dolly features a generous spread and a positive leg locking system that securely captures our TCR100 crane tripod.
TCR100 Crane Tripod
Our specially manufactured crane tripod is the only tripod we recommend for use with any crane, regardless of brand. We recommend never using a telescoping or collapsible tripod under a crane, no matter how small. When an expensive camera carries on a boom elevated over other valuable equipment or people, it's simply a no-brainer to eliminate all risks and use a single cut tripod instead of a telescopic type. The TCR100 crane tripod is manufactured in-house and is specifically designed for use with the DCR100 dolly. Safety and strength are top priorities: The TCR100 uses a solid machined (not cast) base plate and fittings for strength and precision, special tubes, and oversized leveling feet for an ultra-stable design that never wobbles or fails when used properly with the DCR100 dolly.
VariZoom Jibs
are professional tools with quick setup, long-term reliability, and outstanding performance. Take a close look to see the finer details of our thoughtful design, including tool-free assembly and stainless quick-release pins secured by a connector so they never get lost. Scroll down to see how VariZoom takes your investment seriously.
New: The QuickJib comes with the new lightweight, thickly padded soft case from VariZoom.
This heavy case can also be purchased separately and can be used for other jibs. Outside 59 "x12" x11 "; Inside 58 "x11" x10 "; Weight 4.9 lbs. Hard Case is an optional upgrade (63 "x15", 20.5 lbs.)
varizoom quickjib manual english.pdf
