VariZoom VZMC100 Remote Head for cameras up to 12 kg
Pan/Tilt head for camera cranes and broadcast productions
article number: 4991 | manufacturer number: VZMC100 | EAN/UPC: 877038000506
The VariZoom VZMC100 is a professional motorized remote Head for precise pan and tilt movements with cameras up to approx. 12 kg. It is ideal for use on camera cranes, jibs, tripods as well as for stationary remote camera installations in studios, churches, event rooms or broadcast environments.
The system is delivered as a complete set with control box, power supply, cables, mounting material and transport case, making it quick ready for use.
The VZMC100 enables stop-free 360° movements in both axes. The speed can be continuously regulated - from very slow, even camera movements to fast movements for tracking actions.
- 360° pan and tilt without stop
- Infinitely adjustable movement speed
- Smooth and controlled Camera movements
- Suitable for broadcast, events, studio and film production
The free Adjustable X/Y axes make balancing the camera easier. The central cable routing through the axes reduces disruptive tensile forces and supports uniform movements without unnecessary imbalance.
- Fine adjustment via X/Y axes
- Central cable routing through the head
- Low-vibration and clean Movement sequences
The remote head can both overslung (overslung) and underhung (underslung) are used. This means that it can be flexibly adapted to different crane, jib and tripod configurations.
The high-quality construction with precisely manufactured components ensures high reliability in daily production use. The VZMC100 is designed for mobile production, rental applications and fixed installations.
- Robust and maintenance-friendly construction
- Reliable operation with regular use
- Suitable for rental, broadcast and Live production
- VariZoom VZMC100 Remote Head (Pan/Tilt head)
- Control box with Jib clamp for 1"round rod
- Universal power supply (100–240 V)
- Extension cable, approx. 6 m
- Mounting material for cameras, tripods and jibs
- Transport case with precisely fitting foam insert
- Operating instructions
Suitable for camera cranes and jib systems with 100 mm Recording, among others:
- VariZoom QuickJib
- VariZoom SnapCrane
- EZFX crane systems
- and many others with 100mm Halfball or Flatmount
Real product can look different to picture
techn. Specs▲
| Weight | 12.2 kg (27 lbs) |
| Dimensions | 91.4 × 55.9 × 53.3 cm (36 × 22 × 21 in) |
| Head Weight | 3.9 kg (8.5 lbs) |
| UPC | 877038000506 |
| Head Dimensions | 55.9 × 27.9 × 12.7 cm (H 22 × W 11 × D 5 in) |
| Case Dimensions | 63.5 × 50.5 × 22.4 cm (L 25 × W 19.9 × H 8.8 in) |
| Packed Weight | 12.9 kg (28.5 lbs) |
| Max Operating Distance | 152.4 m (500 ft) |
| Max Recommended Camera Weight | Optimal 6.8 kg (15 lbs), Maximum 11.3 kg (25 lbs) |
| Power Requirements |
24VDC 1.25A recommended (via included AC adapter) 14.4VDC 1.5A minimum (up to 48VDC) |
| Construction | Aluminum (powder-coated), Stainless Steel, Delrin |
| Components Included |
Head, Control Box with jib clamp for 1" round bar; 2 custom-geared motors; Universal power adapter (100–240VAC); 20' extension cable (6.1 m); Mounting hardware for cameras, tripods & jibs; Carrying case with custom die-cut foam insert; Manual |
| Warranty | 2-year parts & labor |
| Returns | 15% restocking fee |
Questions & Answers▲
What maximum camera load does the VariZoom VZMC100 carry?
The remote head is designed for cameras weighing up to 12 kg. Within this load limit, the system works reliably and enables precise movement sequences.
What swivel range does the head offer in the pan and tilt directions?
The VZMC100 enables stop-free 360° movements in both the pan and tilt directions Tilt axis. There is no mechanical end stop, so continuous rotational movements are possible without interruption.
Can the movement speed be continuously regulated?
Yes, the speed is continuously adjustable. This allows both very slow, consistent tracking shots as well as fast panning to track dynamic actions.
For which areas of application is the VZMC100 suitable?
The remote head is suitable for camera cranes, jibs and tripods as well as for stationary installations in studios, churches, event spaces and broadcast environments. It is designed equally for mobile productions and fixed installations.
Can the head be mounted overslung or underslung?
Yes, the VZMC100 supports both mounting variants. It can be operated overslung or underslung and thus adapts to different crane, jib and tripod configurations.
How is the camera balanced on the remote head?
The balancing is done via freely adjustable X and Y axes. This fine adjustment allows the camera to be precisely balanced, which promotes low-vibration and consistent movements.
What is meant by the central cable routing of the VZMC100?
The cables are guided through the axes of the head. This reduces disruptive pulling forces from outside, prevents unnecessary unbalance and supports clean, even camera movements.
Which accessories are included in the scope of delivery?
The system is delivered as a complete set and includes the control box, a power supply, the necessary cables, and mounting material and a transport case. This means that the head is ready for use immediately after unpacking.
How is the remote head controlled?
It is controlled via the control box included in the scope of delivery. These can be used to control pan and tilt movements as well as the movement speed.
Is the VZMC100 also suitable for rental operation?
Yes, the robust and maintenance-friendly construction makes the head expressly suitable for Suitable for rental applications. The solid workmanship and the included transport case make frequent assembly and dismantling in rental operations easier.
Can the remote head be operated permanently in a fixed installation?
The VZMC100 is expressly designed for stationary installations, for example in studios, churches or event rooms where the camera is to be remotely controlled and permanently positioned.
What advantages does motorized control offer over a manual fluid head?
A motorized remote head allows operation from a distance without a person having to stand directly at the camera. This enables camera positioning in hard-to-reach places such as the tip of a jib or crane and increases the design possibilities in production and broadcast.
