D-Tap to 4-Pin XLR Adapter Cable 50 cm
Adjustable Angle Connector for Camera Rigs and Broadcast
No returned or B-stock items sold as new
One contact who knows the equipment
Not left alone if a defect occurs
Full input-tax deduction for business customers
article number: 9514 | manufacturer number: DTAP-XLR | EAN/UPC: 758263167335
The PowerTap to XLR adapter cable is used to power cameras, monitors, and video accessories via a PowerTap or D-Tap connection.
The cable is equipped with a 2-pin PowerTap connector, male, and a 4-pin angled XLR connector. The angled connector is freely adjustable and allows flexible cable routing on the device.
With a length of approx. 50 cm, the adapter cable is suitable for camera rigs, battery systems, monitors, and mobile broadcast setups where a compact connection between battery and load is required.
Real product can look different to picture
techn. Specs▲
| Product Type | Adapter cable for power supply |
|---|---|
| Battery Side / Power Supply | PowerTap / D-Tap connector, 2-pin, male |
| Device Side | 4-pin XLR right-angle socket |
| XLR Pin Assignment | Pin 1 = Minus / Pin 4 = Plus |
| PowerTap Contacts | Gold contacts |
| Cable Length | approx. 50 cm |
| Design | XLR right-angle socket, freely adjustable angle |
Questions & Answers▲
What is this cable used for?
This adapter cable connects a PowerTap or D-Tap battery output to a device with a 4-pin XLR power input. It is suitable for powering cameras, monitors, and video accessories in camera rigs, battery systems, and mobile broadcast setups.
What connectors does the cable have on each end?
One end has a 2-pin PowerTap connector (male), also known as D-Tap. The other end has a 4-pin XLR right-angle socket.
What is the pin assignment of the 4-pin XLR connector?
Pin 1 is assigned to minus (ground) and pin 4 is assigned to plus (positive voltage). This is a common standard used in many professional camera and monitor power connections.
How long is the cable?
The cable has a length of approximately 50 cm, making it compact enough for use directly between a battery and an attached device on a camera rig.
What does freely adjustable angle mean in this context?
The XLR right-angle connector can be rotated and repositioned to any desired angle. This allows flexible cable routing depending on the orientation of the device and the layout of the rig.
Are the PowerTap contacts gold-plated?
Yes, the PowerTap connector uses gold contacts, which provide reliable conductivity and good resistance to corrosion over time.
Is this cable compatible with V-Mount and Gold Mount battery systems?
Yes, as long as the battery plate or battery has a PowerTap or D-Tap output port, the cable is compatible regardless of whether the battery uses a V-Mount or Gold Mount attachment.
Can this cable be used to power a monitor on a camera rig?
Yes, provided the monitor has a 4-pin XLR power input with the standard pin assignment of pin 1 minus and pin 4 plus, the cable can be used to supply power from a D-Tap source directly to the monitor.
Is the cable suitable for broadcast applications?
Yes, the cable is designed for use in mobile broadcast setups where a compact and reliable connection between a battery and a powered device is required.
Does the adjustable angle connector help with cable management on rigs?
Yes, the freely adjustable angle of the XLR connector makes it easier to route the cable cleanly alongside rig components, reducing strain on the connector and avoiding unwanted cable tension.
