Lilliput BM150-4KS-LP 15.6 inch 4K HDR field monitor
IPS panel, SDI/HDMI, V-Mount – for studio and field
Special price: € 1129.00
incl. VAT
( instead of 1486.31 )
948.74 € w/o vat
in stock
Shipping costArtikelnummer: 12210 | Hersteller-Nummer: BM150-4KS-LP | EAN:
The Lilliput BM150-4KS-LP with swivel bracket is a 15.6 inch HDR field monitor with true 4K resolution (3840 x 2160 pixels) professional 8-Bit FRC IPS panel for best image quality at 330 cd brightness. According to experts, an 8-bit FRC panel displays the colors/grayscales even better than a pure 10-bit panel. With almost 40cm image diagonal, 3G HD-SDI, DVI and 4 x HDMI IN. Operation with V-Mount batteries or with the included power supply. Including flight case. This monitor also fits perfectly into any 19 inch 6U rack. BM150-4KS - the successor to the legendary BM150-4K - now with HDR and 3D Lut and many new display functions If necessary, the monitor can also be installed directly in a 19 inch rack. The monitor occupies 6 height units (U) and is 483mm wide - so it can be integrated into any rack. Large field monitor with professional connections. Exactly the right device for all those for whom 7-10 inch monitors simply don't have enough of a screen diagonal, and 23 or 28 inches are simply too big. The Lilliput BM150-4KS offers a large display diagonal of 39.7cm (15.6 inches) with a very sharp native resolution of 3840x2160 pixels. Thanks to IPS technology, the display not only represents the colors well, but also has a stable viewing angle.
- Professional video monitor for directing, editing, studio or field use
- Bright and sharp display with 39.7cm image diagonal
- Real resolution of 3840 x 2160 pixels enables native preview of 4K
- IPS technology ensures good contrast and colors that are displayed correctly regardless of the viewing angle
- Precise calibration via RGB controller possible
- Almost all monitor control is via the front keyboard
- Video inputs for 4 x HDMI (1 x 4 K or 4 x HD), VGA, DVI and HD-SDI/SDI in/out
- HDMI input 1 with HDMI 2.0, 4K in 25/30/50/60 HZ is possible
- HDMI input 2-4 with HDMI 1.4, 4K with 25/30 Hz is possible
- SDI input with 3G-SDI FullHD (1920x1080). 50/60 Hz
- 8-bit FRC color processing (according to the manufacturer) - better than 10-bit without FRC
- SDI can be looped through (passthrough)
- The aspect ratio of the image can be set in the device (e.g. to Equalization for anamorphic Cinemascope productions)
- Connection for headphones via 3.5mm small jack
- VESA 100x100 holes for wall mount on the back
- Operation from the socket or via batteries (Sony V-Mount)
- Tally connection via 9-pin SUB-D
- 19 inch rack flight case with lid at the front and back
- Back lid with pocket for storing accessories
- Front lid for storing the sun protection visor and/or protective screen
- Fully assembled swivel frame with 16mm mount for light stands
- Power supply, power cable, power tap to XLR 4-pin cable
- Tally connector (15-pin SubD) for soldering included as a kit
- Stands for operation as a desktop monitor
- Operating instructions
- Screws for mounting the protective screen (pre-assembled)
- Sun protection visor (Velcro fastening to the flight case)
Real product can look different to picture
techn. Specs▲
| Image diagonal | 39.7cm (15.6 inches) |
|---|---|
| Resolution | 3840 x 2160 pixels |
| Screen type | partially anti-reflective |
| Color depth | 8-bit FRC (representation better than 10-bit) |
| Brightness | 330 cd/m² |
| Contrast | 1000:1 |
| Viewing angle | 176° horizontal 176° vertical |
| Operating voltage | 12 to 24V |
| Power consumption | maximum 15 watts |
| Inputs | 1x HD-SDI, 4x HDMI, 1x SDI + Audio, 1x VGA, 2 x Audio RCA |
| Outputs | 1x HD-SDI |
| HDMI input 1 | HDMI 2.0 4K in 25/30/50/60 HZ possible |
| HDMI input 2-4 | HDMI 1.4 4K with 25/30 Hz possible |
| Dimensions (LxWxD) | approx. 389 x 267 x 38mm / 524 x 305 x 170mm (with flight case) |
| Weight | approx. 3.4Kg / 12kg (with flight case) |
Questions & Answers▲
What screen size and resolution does the Lilliput BM150-4KS-LP offer?
The monitor has a screen diagonal of 15.6 inches (39.7 cm) and a native 4K resolution of 3840 x 2160 pixels. This enables a true-to-original preview of 4K material without scaling.
What type of panel is installed and what advantages does it bring?
An 8-bit FRC IPS panel is installed. IPS technology ensures stable viewing angles as well as good contrast and colors. According to experts, the 8-bit FRC panel should display colors and grayscale even better than a pure 10-bit panel.
What brightness does the display achieve?
The display achieves a brightness of 330 cd/m², which is a easy to read use even under more demanding lighting conditions.
Which input connections are available?
The monitor offers four HDMI inputs, a 3G HD-SDI input and a DVI input. This allows various signal sources from studio and field productions to be connected.
How is the monitor supplied with power?
Operation is possible either via V-mount batteries or via the included power supply. This makes the monitor suitable for both stationary studio environments and mobile field use.
Does the monitor support HDR and 3D LUT?
Yes, the BM150-4KS-LP supports HDR and 3D LUT. Compared to the previous model BM150-4K, these functions have been newly added, along with additional display functions.
Can the monitor be installed in a 19-inch rack?
Yes, the monitor can be installed directly into one Integrate standard 19-inch rack. It occupies 6 height units and has a width of 483 mm, which means it fits into any standard rack.
Is a transport case included in the scope of delivery?
Yes, a flight case is included in the scope of delivery, which protects and protects the safe transport of the monitor makes it ideal for mobile use.
For which areas of application is the monitor suitable?
The monitor is suitable for professional applications in directing, editing, studio and field production. It can be used both stationary and mobile and therefore covers a wide range of professional video applications.
How is the monitor controlled?
Almost the entire monitor is controlled via the front keyboard, which means quick and direct operation without additional devices possible.
Is color calibration possible?
Yes, the monitor enables precise calibration via RGB controllers, so that the image display can be precisely tailored to individual requirements or production standards can.
Which swivel bracket or bracket does the monitor contain?
The BM150-4KS-LP is supplied with a tripod frame or swivel bracket, which allows flexible positioning of the monitor on a tripod
What predecessor does the BM150-4KS-LP have and what makes it different?
The BM150-4KS-LP is the successor to the BM150-4K-LP. Compared to its predecessor, the new model also offers HDR support, 3D LUT and other new display functions.
