Hoodman HGCP15 Ground Control Point Kit 1-5
5 ground control points for drone surveying and photogrammetry
No returned or B-stock items sold as new
One contact who knows the equipment
Not left alone if a defect occurs
Full input-tax deduction for business customers
article number: 12783 | manufacturer number: HGCP15 | EAN/UPC: 017932335193
The Hoodman HGCP610 Ground Control Point Kit consists of five round Ground Control Points numbered 6 through 10. Each marker has a diameter of 3 ft or approximately 91.4 cm and deploys quickly into its operational shape thanks to its self-tensioning construction.
The set is designed for professional applications in drone surveying, photogrammetry, aerial surveying, and drone mapping. Clearly visible Ground Control Points support the precise referencing and evaluation of aerial imagery. The HGCP610 is also ideally suited as a complement to the Hoodman HGCP15 with numbers 1 through 5, when a total of up to ten uniquely numbered reference points are required.
The Ground Control Points are made of durable polyester and feature a perimeter galvanized steel cable. The weighted outer edge ensures that the markers hold their position on the ground without the need to drive in stakes for normal use.
For longer-term positioning, each GCP additionally has four attachment loops. These can be used, for example, when animals or other external factors could shift the deployed markers.
24-inch scaling marks are integrated into the pattern of each Ground Control Point. These serve as a defined size reference during subsequent evaluation of the captured image data.
A central grommet allows the precise placement of a surveying rod at the center of the marker, supporting accurate capture of GPS coordinates.
- Drone surveying and drone mapping
- Photogrammetry
- Aerial surveying
- Georeferencing of aerial imagery
- Surveying and documentation projects
- Capturing precise GPS reference points
- Expanding an HGCP15 set to numbering 1 through 10
All five Ground Control Points weigh approximately 22 lb or around 10 kg combined and can be transported compactly in the included carry bag with shoulder strap.
Cleaning is done with mild soap and water. Before storing in the carry bag, the markers should be completely dry to prevent the formation of mold.
- 5 Hoodman Ground Control Points
- Numbering 6 through 10
- Carry bag with shoulder strap
Please note: Images may differ from the product currently supplied. Some product photos have been scaled, background-removed or visually enhanced using artificial intelligence. The product features shown were not intentionally altered.
techn. Specs▲
Specifications
| General | Manufacturer | Hoodman |
|---|---|---|
| Model | HGCP610 | |
| Product Type | Ground Control Point Kit | |
| Number of Ground Control Points | 5 | |
| Numbering | 6 to 10 | |
| Dimensions & Construction | Shape | Round |
| Diameter per GCP | 3 ft / approx. 91.4 cm | |
| Material | Durable Polyester | |
| Outer Edge | Galvanized Steel Cable | |
| Construction | Self-tensioning and self-weighted | |
| Referencing | Scaling Markers | 24 inches |
| Center Grommet | Yes | |
| Grommet Use | Positioning of a surveying rod | |
| Anchor Loops | 4 per Ground Control Point | |
| Transport | Total Weight | 22 lb / approx. 10 kg |
| Carrying Bag | Yes | |
| Shoulder Strap | Yes | |
| Care | Cleaning | Mild soap and water |
| Note | Allow to dry completely before storing |
Explore product ▲
Questions & Answers▲
How many Ground Control Points are included in the Hoodman HGCP15?
The Hoodman HGCP15 kit includes five Ground Control Points numbered 1 through 5. Each marker has a diameter of 3 ft or approximately 91.4 cm.
What applications is the Hoodman HGCP15 suitable for?
The HGCP15 is designed for drone surveying, photogrammetry, drone mapping, aerial surveying, and other surveying and documentation projects that require clearly visible reference points on the ground.
Do the Hoodman Ground Control Points need to be secured with stakes?
In normal use, additional securing is not strictly necessary. The weighted outer edge helps keep the markers in position. For longer-term placement, four securing loops are available on each Ground Control Point.
What are the 24-inch markings on the Ground Control Points for?
24-inch scaling markings are integrated into the pattern of each Ground Control Point. They provide a defined size reference within the marker and can be used when evaluating and referencing survey and aerial imaging data.
How can the GPS coordinates of a Ground Control Point be determined precisely?
Each Ground Control Point has an eyelet at the center of the marker. A surveying rod can be positioned there, allowing GPS coordinates to be captured directly at the center of the reference point.
What is the difference between the HGCP15 and a kit numbered 6 through 10?
The HGCP15 includes five Ground Control Points numbered 1 through 5. Hoodman also offers the same numbered markers as a set numbered 6 through 10. This allows multiple uniquely numbered Ground Control Points to be used in larger projects.
