Varizoom Vzquickjib2 Camera Crane With Extension
Universal Big Jib System - Useable Nearly Everywhere
Artikelnummer: 10122 | Hersteller-Nummer: VZQUICKJIB2 | EAN: 877038008267
- QuickJib (Jib only) and Jib Extension (Without tripod and dolly and remote head)
- VZQUICKJIB2 CAMERA JIB CAMERA CRAN
| Jib Arm | The QuickJib uses selective industrial powder coating and anodizing for lasting cosmetics, with stainless steel fasteners. The sleek QuickJib outperforms the competition with less air resistance using a four-arm support system (never use in high wind conditions). The QuickJib is mounted on any 100mm tripod, although we only recommend non-telescoping legs for safety reasons. |
|---|---|
| Braking System | The VariZoom braking system uses a heavy-duty plate that is firmly connected to the swivel range. The brake compression system is integrated into the left stator of the swivel/tilt base and is designed to add significant variable resistance but makes enough mistakes to slide under extreme force that could otherwise overturn a parking brake boom system. |
| Locking Pins | High-quality, high-strength stainless steel aircraft bolts are used at the pivot points, secured by a connector to prevent them from being lost. |
| Tilting Mechanisms | The camera platform and tilt base connect the boom arm with stainless steel aircraft pins, which are introduced through sealed radial ball bearings at the tilt base and high-performance slide bearings at the camera platform, resulting in quiet, smooth movement. The camera platform also features a built-in spirit level for quick reference and adjustment. |
| Telescoping Counterweight Section | Telescoping counterweight arm with up to 3 feet for tremendous flexibility. Extend the arm to reduce the required weight, shorten it to work in tighter spaces, or simply adjust it to fine-tune the counterweight. |
- DCR100 Dolly (optional, not included) - Our heavy-duty dolly features a generous spread and a positive leg locking system that securely accommodates our TCR100 crane tripod.
- TCR100 Crane Tripod (optional, not included) - Our custom-made crane tripod is the only tripod we recommend for use with any crane, regardless of brand. We recommend never using a telescoping or collapsible tripod under a crane, no matter how small. When an expensive camera carries over other valuable equipment or people on an elevated boom, it's simply a no-brainer to eliminate all risks and use a single-cut tripod instead of a telescopic type.
Real product can look different to picture
techn. Specs▲
| Weight | approx. 33Kg |
|---|---|
| Dimensions | 60 x 13 x 13 inches |
| Tripod to Camera Reach | 5 ft standard, 9.5 ft w/ optional extension |
| Max. Camera Height (with MC100 overslung) | 9.5 ft standard, 13 ft w/ optional extension |
| Vertical Movement (ground to camera platform at maximum height) | 7.5 ft standard, 11 ft w/ optional extension |
| Max Weight Capacity | 50 lbs standard, 30 lbs w/ optional extension |
| Head Mount Type | 100mm standard, optional adapters for 75mm, Mitchell or Flat |
| Jib-to-Tripod Mount Type | 100mm flat (no leveling ball), optional Mitchell adapter available |
| Telescoping Tail Range | Up to 3 feet |
| Jib Weight | 27 lbs standard, 47 lbs extended |
| Minimum Storage Length | 56 inches |
