Lilliput FS7 – 7-inch on-camera monitor with SDI & HDMI
Professional 4K camera monitor with metal housing
Special price: € 269.00
incl. VAT
( instead of 284.41 )
226.05 € w/o vat
product already ordered
Shipping cost More from LilliputNo returned or B-stock items sold as new
One contact who knows the equipment
Not left alone if a defect occurs
Full input-tax deduction for business customers
article number: 11989 | manufacturer number: FS7 | EAN/UPC: 6950821601433
The Lilliput FS7 is a compact 7-inch on-camera monitor for camera, video, and production applications. Its form factor makes it suitable as a confidence monitor directly on the camera, on a rig, or in mobile production environments.
The display offers high resolution and supports monitoring of modern video signals. This allows the monitor to be used in film, broadcast, streaming, and content productions for evaluating framing, focus, and signal.
The FS7 features HDMI and 3G-SDI connections with loop output. This allows an incoming signal to be passed on to additional devices such as monitors, recorders, or production desks.
The combination of HDMI and SDI allows the monitor to be used flexibly with a variety of cameras, playback sources, and production systems.
Various assistance functions are available for image monitoring. These include peaking for focus evaluation, aspect markers, audio level meter, and histogram.
These tools assist with monitoring focus, framing, exposure, and audio signal during recording or production.
The metal housing protects the monitor during everyday production use and makes it suitable for mobile on-set applications. Via a compatible Sony NP-F battery plate, the monitor can be flexibly powered using compatible batteries.
The compact design facilitates mounting on camera setups, rigs, or brackets, and enables use in varying shooting situations.
The Lilliput FS7 is suitable for camera work, film and video production, broadcast applications, live streaming, mobile productions, and content creation.
- Foldable sun hood
- 100–220 V / 12 V power supply
- Battery plate for Sony NP-F series
- HDMI A/C cable
- Hot shoe articulating adapter
Please note: Images may differ from the product currently supplied. Some product photos have been scaled, background-removed or visually enhanced using artificial intelligence. The product features shown were not intentionally altered.
techn. Specs▲
| Größe | 7" | |
|---|---|---|
| Resolution | 1920 x 1200 | |
| Brightness | 500cd/m² | |
| Aspekt Verhältnis | 16:10 | |
| Contrast | 1000:1 | |
| Anzeigen Winkel | 170°/170°(H/V) | |
| SDI | 1×3G | |
| HDMI | 1×HDMI 1,4 | |
| SDI | 1×3G | |
| HDMI | 1×HDMI 1,4 | |
| SDI | 720p 50/60, 1080i 50/60, 1080p5F 24/25/30, 1080p 24/25/30/50/60 | |
| HDMI | 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60, 2160p 24/25/30 | |
| SDI | 12ch 48kHz 24-Bit | |
| HDMI | 2ch Eingebaut Lautsprecher | 1 |
| Operatingsleistung | ≤12W | |
| DC In | DC 7-24V | |
| Kompatible Batterien | NP-F Serie | |
| Inputsspannung (Batterie) | 7,2 V nominal | |
| In Operating Temperatur | 0°C~50°C | |
| Storage Temperatur | -20°C~60°C | |
| Dimensions (LWD) | 182×124×22mm | |
| Weight | 405g |
Questions & Answers▲
What screen size does the Lilliput FS7 have?
The monitor has a screen diagonal of 7 inches. This size offers a good balance between clear display and compact design, making it well suited as a camera attachment monitor for mobile shoots.
What native resolution does the display offer?
The display of the Lilliput FS7 supports a native 4K resolution of 3840 × 2160 pixels. This enables precise and detailed image control directly on the camera.
Which input and output connections are available?
The monitor has a 4K HDMI input and a 3G-SDI input, each with a loop output function. This means that the incoming signal can be forwarded to other monitors or recording devices without loss of quality.
What is the loop output function and what is it used for?
The loop output function allows the incoming signal to be looped through and sent to a device at the same time output to another device, such as a second monitor or a recording device. The signal level remains unchanged, which ensures loss-free transmission.
What monitoring tools are available?
The Lilliput FS7 offers, among other things, a peaking filter for sharpness control, an aspect marker for monitoring various image formats Audio level meter and a histogram for technical image analysis. These tools help camera operators to keep a precise eye on image and sound parameters during recording.
How does the peaking filter work?
The peaking filter highlights edges in the image that are in the focus area in color. This makes it much easier and safer to control the focus on the camera, especially for critical shots with a shallow depth of field.
What material is the housing made of?
The housing is made of metal. This robust construction protects the display and the internal electronics from mechanical stress that can arise during mobile production or frequent transport.
What power supply options are there?
The monitor is compatible with a Sony NPF Battery Plate, so it can be powered via commercially available ones Sony NP-F batteries can be operated. This makes a flexible and reliable power supply possible even without a mains connection.
What areas of application is the monitor suitable for?
The Lilliput FS7 is aimed at filmmakers, content creators and cameramen who need professional image control directly on the camera. The SDI support makes it also suitable for broadcast applications, while the compact design is suitable for mobile filming.
Does the monitor support different aspect ratios?
Yes, different image formats and aspect ratios can be displayed on the monitor using the aspect marker function Show display. This is helpful when material is produced for different output formats at the same time or one after the other.
What does the histogram show?
The histogram graphically displays the brightness distribution of the image signal. In this way, over- and underexposure can be quickly identified and the Correct the exposure settings on the camera accordingly.
Can the monitor process both HDMI and SDI signals at the same time?
The monitor has separate HDMI and SDI inputs. Whether both signals can be actively used at the same time depends on the respective operating mode. The loop output function is available for both connection types in order to route the signal flexibly.
How heavy is the monitor and what dimensions does it have?
There is no reliable manufacturer information on the exact weight and dimensions of the Lilliput FS7 before. For binding technical data, we recommend taking a look at the manufacturer's official data sheet.
