Lilliput PVM210S 21.5 inch monitor 1000 nit
Professional video monitor for broadcast, drone & fawn search
Special price: € 589.00
incl. VAT
( instead of 617.61 )
494.96 € w/o vat
in stock
Shipping costArtikelnummer: 12316 | Hersteller-Nummer: PVM210S | EAN: 6950821601822
The LILLIPUT PVM210S is a professional 21.5 inch video monitor with very good performance characteristics for bright environments. With a high brightness of 1000 nits, the monitor ensures clear and high-contrast images even in daylight or in mobile outdoor use. This makes the monitor ideal for fawn hunting, especially in conjunction with drones, thermal imaging cameras or live image transmission systems.
The LILLIPUT PVM210S was specifically developed for use in broadcast, film and content creation environments. The monitor combines high-quality image reproduction with comprehensive monitoring functions and offers content creators, filmmakers and broadcast professionals the precise image control required for professional productions.
Center and safety markers support precise image division and help to correctly position important image elements. The integrated layout and composition functions offer various guides and markings, which are particularly beneficial during interviews, productions or live events. This means that all relevant content remains reliably in the visible area.
An integrated audio level monitoring system enables precise monitoring of audio levels directly on the monitor. The Audio Level Meters provide a visual representation of input levels, helping to avoid clipping and ensuring consistent audio quality. This makes the monitor ideal for studios, outdoor broadcasts and post-production environments.
With an impressive brightness of 1000 nit, the PVM210S offers excellent visibility even in difficult lighting conditions. This high luminance makes the monitor particularly suitable for outdoor recordings, mobile use and brightly lit studio environments. The integrated HDR support also enables accurate playback of high dynamic range content with precise color representation.
The monitor can be used flexibly for fawn searches and other drone jobs. With suitable brackets, the monitor can be mounted directly on tripods, thereby providing a stable working position in the field. The HDMI, SDI and VGA inputs make the monitor particularly universally applicable and compatible with numerous cameras, drone systems, receivers and video sources.
The extensive connection options enable flexible integration into a wide variety of production workflows. Professional video inputs ensure compatibility with a wide range of cameras and recording devices. The wall-mount functionality also enables space-saving installation in studios, vehicles or control rooms.
The monitor comes complete with power supply (15V/4A), HDMI cable A-A, VGA cable, Audio/video cable and stands supplied.
Real product can look different to picture
techn. Specs▲
| Model | PVM210S |
|---|---|
| Panel | 21.5" LCD |
| Physical resolution | 1920*1080 |
| Aspect ratio Ratio | 16:9 |
| Brightness | 1000 cd/m² |
| Contrast | 1500: 1 |
| Viewing angle | 170°/170°(H/V) |
| Color space | 101% Rec.709 |
| HDR supported | HLG;ST2084 300/1000/10000 |
| SDI | 1 x 3G SDI |
| HDMI | 1 x HDMI 1.4b |
| VGA | 1 |
| AV | 1 |
| SDI | 1 x 3G-SDI |
| SDI formats | 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60... |
| HDMI | 2160p 24/25/30, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60... |
| Speakers | 2 |
| SDI | 16ch 48kHz 24-bit |
| HDMI | 8-channel 24-bit |
| Headphone jack | 3.5mm 2-channel 48 kHz 24-bit |
| Input voltage | DC12-24V |
| Power consumption | ≤36W (15V) |
| Operating Temperature | 0°C~50°C |
| Storage Temperature | -20°C~60°C |
| Dimension (LWD) | 524.8*313.3*19 mm |
| Weight | 4.8 kg |


Questions & Answers▲
What screen diagonal does the monitor have?
The monitor has a screen diagonal of 21.5 inches with a resolution of 1920x1080 pixels in a 16:9 aspect ratio.
How bright is the display and what areas of use is it suitable for?
The display achieves a brightness of 1000 cd/m² and is therefore ideal for bright environments, for example when searching for fawns with drones or other outdoor operations.
What connection options does the monitor offer?
The monitor has a variety of inputs: 1x 3G-SDI, 1x HDMI 1.4b, 1x VGA and 1x AV input. These universal connections enable flexible use with various devices.
Which SDI formats are supported?
The monitor supports various SDI formats: 1080p in 24/25/30/50/60 Hz, 1080i in 50/60 Hz and 720p in 50/60 Hz via the 3G-SDI input.
Does the monitor support HDR content?
Yes, the monitor supports HDR formats such as HLG and ST2084 with different brightness levels (300/1000/10000 nits) for extended color display.
What is the viewing angle of the display?
The LCD panel offers a wide viewing angle of 170° both horizontally and vertically, ensuring good visibility from various positions.
What audio features are available?
The monitor has integrated speakers and supports 16-channel 48kHz 24-bit audio via SDI, 8-channel 24-bit via HDMI and a 3.5mm jack connection for 2-channel audio.
What are the power supply and consumption?
The monitor works with an input voltage of DC 12-24V and has a maximum power consumption of 36W at 15V.
In what temperature range can the monitor be operated?
The monitor is designed to operate in a temperature range of 0°C to 50°C and can be stored at -20°C to 60°C.
What are the dimensions and weight?
The dimensions are 524.8 x 313.3 x 19.8 mm and weighs 4.8 kg. The compact design enables flexible mounting on tripods.
Which color space does the monitor cover?
The monitor covers 101% of the Rec.709 color space and therefore offers very good color reproduction for video and surveillance applications.
