DBSTAR HVT11 LED Wall Sending Card PCI

Name: DBSTAR HVT11 Sending card PCI
Brand: DBSTAR
SKU: HVT11
Price: 399.00 EUR
Availability: InStock

HDMI/DVI input, dual LAN ports, PWM3 for Series 11 and 09

1 / 3

€ 399.00
incl. VAT

335.29 € w/o vat

in stock

Shipping cost

description:

article number: 10927 | manufacturer number: HVT11

Control card - Sending Card PCI DBSTAR HVT11

for installation in PC MAC or Scaler

For controllingDBSTARsystems of the 11 and 09 series.

The sending card is installed in the PC, MAC or scaler. The control is via HDMI or DVI connection. It then goes to the LED wall via an RJ45 connection/network plug.

Two network connections for high resolutions or high security in control.

Item characteristics

supports RGB
full PWM3 support of the 11 series - EMC compliant signal processing
Sound support
Backup function for secure signal lines
DVI input signal
Supports HDMI 1.3B, AADCP1.2 protocol
Rotation angle 0/90/180/270 degrees
USB port, single card can drive 1280*1024, 1024*1200, 2048*640 pixels

If the card is returned, a verification fee of 50 euros will be charged.

Real product can look different to picture

techn. Specs▲

Features

Support RGB, the maximum number of colors supported is one billion
Support sound transmission
Support hot backup of dual LAN lines
Support input of DVI digital signal
Support HDMI 1.3B standard, support AADCP1.2 protocol
Rotation angles 0, 90, 180, 270
Support encryption time by software setting
Support dual ports lateral, blank line and insert line setup
Working voltage range: 100-240V AC 50/60HZ
USB port communication single card can drive 1280x1024, 1024x1200, 2048x640
Support OE and PWM brightness adjustment, turn on/off and lock screen through the panel key
