AVMATRIX MV0430 3G-SDI QUAD SPLIT Multiviewer
Multiviewer: can display 4 SDI sources on up to 2xSDI and 1xHDMI
Artikelnummer: 12030 | Hersteller-Nummer: MV0430 | EAN: 6971118000067
for up to 4 SD/HD/3G-SD video sources and output on up to 2 SDI monitors or one HDMI monitor.
The AVMATRIX MV0430 3G-SDI QUAD SPLIT multiviewer can support up to 4 SDI Display input signals on 2 SDi monitors and one HDMI monitor.
The configuration is carried out using dip switches or PC software.
Many pre-built views of the output can be selected.
Real product can look different to picture
techn. Specs▲
| Connections | SDI video input | SD/HD/3G-SDI (75Ω) × 4 |
|---|---|---|
| SDI Video Output | SD/HD/3G-SDI (75Ω) × 2 | |
| HDMI Video Output | HDMI Type A × 1 | |
| Standard | SDI input formats | 1080p 60/59.94/50/30/29.97/25/24/23.98 1080PsF 30/29.97/25/24/23.98 1080i 60/59.94/50 720p 60/59.94/50/30/29.97/25/24/23.98 625i 50 PAL 525i 59.94 NTSC |
| SDI & HDMI output formats | 1080p 60/50/30/25/24 1080i 60/50 720p 60/50/30/25 | |
| SDI video standard | SD / HD / 3G-SDI | |
| SDI standards | SMPTE 292M / SMPTE 259M / SMPTE 424M | |
| SDI & HDMI color space | YUV or RGB (input), YUV (output) | |
| SDI auto-switching | Automatic detection of SD, HD and 3G-SDI | |
| Operation | DIP switch | Configuration |
| LAN port | Configuration and Firmware updates | |
| USB port | USB keyboard | |
| Dimensions | Dimensions (L × W × H) | 125.5 × 104 × 24.5 mm |
| Weight | 465 g | |
| Power supply | Mains connection | Lockable Screw connector |
| Power consumption | 6 W | |
| Voltage range | DC 6-24 V | |
| Environment | Operating Temperature | -20 °C to +60 °C (HDMI output: 0 °C to +60 °C) |
| Storage temperature | -30 °C to +70 °C | |
| Relative humidity | 0% - 90%, not condensing | |
| Warranty | Warranty | 3 year limited Manufacturer's warranty |
Questions & Answers▲
How many SDI inputs does the device support?
The device has 4 SDI inputs that can process SD/HD/3G-SDI signals with 75Ω impedance.
Which outputs are available?
The multiviewer offers 2 SDI outputs and 1 HDMI output (Type A) for simultaneous display of the input signals.
How is the device configured?
The configuration is done via DIP switches on the device or by PC software via the LAN port. There are many pre-built views to choose from.
Which SDI formats are supported at the input?
Supports 1080p, 1080PsF, 1080i, 720p in various refresh rates as well as 625i PAL and 525i NTSC according to SMPTE 292M, 259M and 424M standards.
What are the dimensions of the device?
The dimensions are 125.5 × 104 × 24.5 mm with a weight of 465 g, allowing for compact installation.
What power supply does the device require?
The device works with DC 6-24 V via a lockable screw connector and has a power consumption of only 6 W.
Does the device automatically recognize different SDI standards?
Yes, the device has automatic detection and switching between SD, HD and 3G-SDI formats.
In what temperature range can the device be operated?
The operating temperature range is -20°C to +60°C, with the HDMI output requiring a range of 0°C to +60°C.
Which color spaces are supported?
YUV or RGB color spaces are supported at the input, while YUV color space is used at the output.
Can a USB keyboard be connected?
Yes, the device has a USB port for connecting a USB keyboard for operation.
How long is the manufacturer's warranty?
The device comes with a 3-year limited manufacturer's warranty.
documents, files, links▲
avmatrix-mv0430-4ch multiviewer api guide _ver1.0 20180704.pdf
avmatrix ethernet control_mv0430_v1.0.2.0_20180116.zipproduct safety (GPSR)▲
