HD compatible (supports 480p/i, 576p/i, 720p, 1080i/p)
• LED backlight provides longer life, uses less power and provides better color saturation NEW
• RS-232 feature allows external devices to control the monitor through the serial port.
• Underscan capability
• Blue gun feature provides for easy adjustment of screen display

LED- Backlight !
NTSC/PAL (auto sensing) / 800 (H) x 480 (V) dots
Dot Pitch 0.19(H) x 0.19(V)mm
Brightness 350 cd/m² (Nit)
Contrast Ratio: 300 : 1
Number of pixels: 1.2 M
Viewing angle L/R/T/B:: 65/65/55/60 degrees
Pixel Confi guration: Stripe
Power Requirements: 11~24 VDC b1 20%, 500mA, + pin, - ground
Power Consumption: 4 W (max)
Video Input Level: 1.0 V P-P (positive) 75 Ohm
LCD-703: Dimensions (WHD): 171 x 133 x 35mm / 6.7 x 5.24 x 1.4
(Height including 5mm mounting pad: 133 + 5mm = 138mm)
Operating temperature: 10 ~ 104°F / -12 ~ 40°C
Storage temperature: -13 ~ 140°F / -25 ~ 60°C
Rear inputs: BNC composite video IN/OUT, S-Video IN/OUT, BNC component IN/OUT, RS-232, Tally , DVI,2.1mm DC IN jack
Weight: Net: 0.7 kg./ 1.5 lbs Gross: TBD

The ToteVision LCD560 is a compact monitor with 2 x composite video inputs and a high-quality metal housing.

• NTSC/PAL composite video
• 2 Video inputs
• LED backlight
• No audio
• 300 Nit brightness
• 300:1 contrast
• 960 x 234 resolution
• Power supply included
• Built-in 1/4-20 mounting pad
• VESA 75mm compliant

The ToteVision MB-1 is a table base for setting up 4-7 inch monitors. The monitor is attached with a 1/4 inch screw.

1 / 4-20 UNC
Suitable for (for example): ToteVision LCD-410, LCD-411, LCD-501, LCD-562, LCD-565, LCD-566T, LCD-640, and LCD-702.

The ToteVision LCD-562 5.6 inch Monitor with Audio, Batterypack, NTSC/PAL and LED Backlight

Mount: Free-standing, 1/4-20 pad
Display 5.6 TFT LCD
Resolution 960 x 234 dots
Native Aspect Ratio 4:3
Visible Screen Size 113.3 x 85mm / 4.5 x 3.3
Back Light LED (30K)
Brightness 200 cd/m² (Nit)
Contrast 300:1
Dot Pitch 0.188mm(H) x 0.362(V)mm
Color Depth unlimited analog
Pixel Configuration RGB Stripe
Response Time 15/20ms (Rising/Falling)
Viewing Angle 65/65/55/55 degrees
Composite x1 RCA video IN/OUT jack on cable
Audio Yes

Tote bag w/ sunshield for LCD-562 and LCD-565

The Tote Vision TB-703HD Tote Bag with Sun Shield (Blue) is designed to carry the Tote Vision LCD-703HD 7.0 LCD field monitor. The bag is carried by an included shoulder strap, and has a pouch on the back for cables and a rechargeable battery. The monitor can be used while in the bag. It is supplied with a sun shield.

Canvas like nylon bag designed to carry a field monitor
Sun shield is included, to block the sun when the monitor is used in the case
Pouch at the rear holds cables and rechargeable battery pack
Slot for cables enables you to use the monitor while it is in the case
Carried with the included shoulder strap
Compatible with Tote Vision LCD-703HD Active Matrix 7.0 color LCD field monitor

High End video monitor with HDMI , S-Video,CVBS and component input.
HD compatible (supports 480p/i, 576p/i, 720p, 1080i/p)
• LED backlight provides longer life, uses less power and provides better color saturation NEW
• RS-232 feature allows external devices to control the monitor through the serial port.
• Underscan capability
• Blue gun feature provides for easy adjustment of screen display

Weight: Net: 0.7 kg./ 1.5 lbs Gross: TBD

This 9.7 commercial-grade monitor features the latest screen imaging technology for enhanced clarity and sharpness. Both analog and digital video will benefit by being viewed on this monitor, and it is the best match for displaying higher resolution megapixel imagery.

Displays HD signals (1080i/p)
LED backlight for better color, longer-life, and lower power
Wide viewing angle (89/89/89/89)
Multiple connections including 2x BNC composite Input / Output for looping
Excellent contrast ratio
Image enhancing - 3D Interlace comb filter, DNR, 4H filter
Durable metal case

• Displays HD signals (1080i/p)
• LED backlight for better color, longer-life, and lower power
• Wide viewing angle (89/89/89/89)
• Multiple connections including 2x BNC composite Input / Output for looping for each monitor
• Excellent contrast ratio
• Image enhancing - 3D Interlace comb filter, DNR, 4H filter
• Built-in stereo speakers
• Durable metal case

Three 5 LCD monitors housed together in a rack mount featuring the latest screen imaging technology for enhanced clarity and sharpness. Both mega-pixel digital and high resolution line analog video will benefit by being viewed on these monitors.

LED backlight provides a brighter picture using less power
Loop-through HDMI and Composite (CVBS) Connections
Multiple features include Pixel to Pixel, Center Marker (80%, 85%, 90%, 93%, 96%, 2.35:1), Image Flip, Check Field, and Image Freeze
Monochrome and color peaking modes for fine control optimizing focus
Built-in Tally indicators (Red, Green, Yellow LED lights)
Durable metal housing with slim <2 depth and 2RU height

same as LCD-HD703, including:

* VZ-CC Case
* Battery-System 2000 mAh with charger at 100-240 Volt and 12 Volt car-battery
( Charging time about 1.5 hours / Running time with LCD703HD about 3 hours at full brightness ! )
* Swivel Mount shoe
* HDMI Adapter to DVI

without SunShield -> please order Sun-Hood extra !

HD compatible (supports 480p/i, 576p/i, 720p, 1080i/p)
• LED backlight provides longer life, uses less power and provides better color saturation NEW
• RS-232 feature allows external devices to control the monitor through the serial port.
• Underscan capability
• Blue gun feature provides for easy adjustment of screen display

LED- Backlight !
NTSC/PAL (auto sensing) / 800 (H) x 480 (V) dots
Dot Pitch 0.19(H) x 0.19(V)mm
Brightness 350 cd/m² (Nit)
Contrast Ratio: 300 : 1
Number of pixels: 1.2 M
Viewing angle L/R/T/B:: 65/65/55/60 degrees
Pixel Confi guration: Stripe
Power Requirements: 11~24 VDC b1 20%, 500mA, + pin, - ground
Power Consumption: 4 W (max)
Video Input Level: 1.0 V P-P (positive) 75 Ohm
LCD-703: Dimensions (WHD): 171 x 133 x 35mm / 6.7 x 5.24 x 1.4
(Height including 5mm mounting pad: 133 + 5mm = 138mm)
Operating temperature: 10 ~ 104°F / -12 ~ 40°C
Storage temperature: -13 ~ 140°F / -25 ~ 60°C
Rear inputs: BNC composite video IN/OUT, S-Video IN/OUT, BNC component IN/OUT, RS-232, Tally , DVI,2.1mm DC IN jack
Weight: Net: 0.7 kg./ 1.5 lbs Gross: TBD

Mounting plate to mount the ToteVision LCD 703 HD upside down!

Dimensions: (W / D / H in mm) 35/25/5

2 x holes for 2 threaded fixing screws
1 x center hole 5mm
1 x 1/4 inch thread
including screws
Mounting plate to mount the ToteVision LCD 703 HD upside down!
